TCA4311ADGKR データシート

Name: TCA4311ADGKR
Brand: TI
SKU: 300310783-0000-0000-0000

TCA4311ADGKR - TI の商品詳細ページです。

２営業日以内に回答いたします

TCA4311ADGKR の詳細情報

型番	TCA4311ADGKR
メーカー	TI
データシート
Interface IC Type	BUS BUFFERS
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e4
Length	3 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Seated Height-Max	1.1 mm
Supply Voltage-Max	5.5 V
Supply Voltage-Min	2.7 V
Supply Voltage-Nom	3.3 V
Supply Voltage1-Max	5.5 V
Supply Voltage1-Min	2.7 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3 mm
