SNJ54HC10J

Name: SNJ54HC10J
Brand: TI
SKU: 290038938-0000-0000-0000

SNJ54HC10J - TI の商品詳細ページです。

２営業日以内に回答いたします

SNJ54HC10J の詳細情報

型番	SNJ54HC10J
メーカー	TI
Family	HC
JESD-30 Code	R-GDIP-T14
JESD-609 Code	e0
Length	19.56 mm
Load Capacitance (CL)	50 pF
Logic IC Type	NAND GATE
Max I(ol)	0.0052 Amp
Number of Functions	3
Number of Inputs	3
Number of Terminals	14
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-55 Cel
Package Body Material	CERAMIC, GLASS-SEALED
Package Code	DIP
Package Equivalence Code	DIP14,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Packing Method	TUBE
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	2/6 V
Power Supply Current-Max (ICC)	0.08 mA
Prop. Delay@Nom-Sup	29 ns
Propagation Delay (tpd)	29 ns
Qualification Status	Not Qualified
Schmitt Trigger	NO
Screening Level	MIL-PRF-38535
Seated Height-Max	5.08 mm
Sub Category	Gates
Supply Voltage-Max (Vsup)	6 V
Supply Voltage-Min (Vsup)	2 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	MILITARY
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	6.67 mm
