SN74LVC2G06DCKR データシート

Name: SN74LVC2G06DCKR
Brand: TI
SKU: 290037674-0000-0000-0000

SN74LVC2G06DCKR - TI の商品詳細ページです。

２営業日以内に回答いたします

CMOS標準ロジックIC

SN74LVC2G06DCKR の詳細情報

型番	SN74LVC2G06DCKR
メーカー	TI
種別	CMOS標準ロジックIC
データシート
Family	LVC/LCX/Z
JESD-30 Code	R-PDSO-G6
JESD-609 Code	e4
Length	2 mm
Load Capacitance (CL)	50 pF
Logic IC Type	INVERTER
Max I(ol)	0.032 Amp
Moisture Sensitivity Level	1
Number of Functions	2
Number of Inputs	1
Number of Terminals	6
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Characteristics	OPEN-DRAIN
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP6,.08
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Power Supplies	3.3 V
Power Supply Current-Max (ICC)	0.01 mA
Prop. Delay@Nom-Sup	3.9 ns
Propagation Delay (tpd)	7.2 ns
Qualification Status	Not Qualified
Schmitt Trigger	NO
Seated Height-Max	1.1 mm
Sub Category	Gate
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	1.65 V
Supply Voltage-Nom (Vsup)	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	AUTOMOTIVE
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	1.25 mm
