SN74CBTLV16211GR データシート

Name: SN74CBTLV16211GR
Brand: TI
SKU: 290035201-0000-0000-0000

SN74CBTLV16211GR - TI の商品詳細ページです。

２営業日以内に回答いたします

SN74CBTLV16211GR の詳細情報

型番	SN74CBTLV16211GR
メーカー	TI
データシート
Additional Feature	TTL COMPATIBLE BUS SWITCH
Control Type	ENABLE LOW
Count Direction	BIDIRECTIONAL
Family	CBTLV/3B
JESD-30 Code	R-PDSO-G56
JESD-609 Code	e4
Length	14 mm
Logic IC Type	BUS DRIVER
Moisture Sensitivity Level	1
Number of Bits	12
Number of Functions	2
Number of Ports	2
Number of Terminals	56
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Characteristics	3-STATE
Output Polarity	TRUE
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP56,.3,20
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Power Supplies	2.5/3.3 V
Power Supply Current-Max (ICC)	0.01 mA
Prop. Delay@Nom-Sup	0.25 ns
Propagation Delay (tpd)	0.25 ns
Qualification Status	Not Qualified
Seated Height-Max	1.2 mm
Sub Category	Bus Driver/Transceivers
Supply Voltage-Max (Vsup)	3.6 V
Supply Voltage-Min (Vsup)	2.3 V
Supply Voltage-Nom (Vsup)	2.5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Translation	N/A
Width	6.1 mm
