SN65LVDS32PWR データシート

Name: SN65LVDS32PWR
Brand: TI
SKU: 290109407-0000-0000-0000

SN65LVDS32PWR - TI の商品詳細ページです。

２営業日以内に回答いたします

SN65LVDS32PWR の詳細情報

型番	SN65LVDS32PWR
メーカー	TI
データシート
Differential Output	NO
High Level Input Current-Max	1.0E-5 Amp
Input Characteristics	DIFFERENTIAL
Interface IC Type	LINE RECEIVER
Interface Standard	EIA-644; TIA-644
JESD-30 Code	R-PDSO-G16
JESD-609 Code	e4
Length	5 mm
Moisture Sensitivity Level	1
Number of Functions	4
Number of Terminals	16
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Low Current-Max	0.008 Amp
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP16,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3.3 V
Qualification Status	Not Qualified
Receive Delay-Max	3 ns
Receiver Number of Bits	4
Seated Height-Max	1.2 mm
Sub Category	Line Driver or Receivers
Supply Current-Max	18 mA
Supply Voltage-Max	3.6 V
Supply Voltage-Min	3 V
Supply Voltage-Nom	3.3 V
Supply Voltage1-Max	3.6 V
Supply Voltage1-Min	3 V
Supply Voltage1-Nom	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	4.4 mm
