PCM3010DB データシート

Name: PCM3010DB
Brand: TI
SKU: 260037761-0000-0000-0000

PCM3010DB - TI の商品詳細ページです。

２営業日以内に回答いたします

PCM3010DB の詳細情報

型番	PCM3010DB
メーカー	TI
データシート
Additional Feature	ALSO REQUIRES 3V TO 3.6V SUPPLY
Consumer IC Type	CONSUMER CIRCUIT
JESD-30 Code	R-PDSO-G24
JESD-609 Code	e4
Length	8.2 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Terminals	24
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-25 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SSOP
Package Equivalence Code	SSOP24,.3
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3.3,5 V
Qualification Status	Not Qualified
Seated Height-Max	2 mm
Sub Category	Other Consumer ICs
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	4.5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	OTHER
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	5.3 mm
