P82B96DGKR データシート

Name: P82B96DGKR
Brand: TI
SKU: 260032364-0000-0000-0000

P82B96DGKR - TI の商品詳細ページです。

5時間51分後以内に見積もり依頼を頂ければ、
11月05日(火) 9:00 までに見積もり回答いたします。

検討リストに追加する

P82B96DGKR の詳細情報

型番	P82B96DGKR
メーカー	TI
データシート
Differential Output	NO
Driver Number of Bits	2
Input Characteristics	STANDARD
Interface IC Type	LINE TRANSCEIVER
Interface Standard	GENERAL PURPOSE
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e4
Length	3 mm
Moisture Sensitivity Level	1
Number of Functions	2
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP8,.19
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	2/15 V
Qualification Status	Not Qualified
Receive Delay-Max	0 ns
Receiver Number of Bits	2
Seated Height-Max	1.1 mm
Sub Category	Other Interface ICs
Supply Current-Max	2 mA
Supply Voltage-Max	15 V
Supply Voltage-Min	2 V
Supply Voltage-Nom	5 V
Supply Voltage1-Max	15 V
Supply Voltage1-Min	2 V
Supply Voltage1-Nom	2.5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3 mm
