OPA820IDR データシート

Name: OPA820IDR
Brand: TI
SKU: 250007892-0000-0000-0000

OPA820IDR - TI の商品詳細ページです。

２営業日以内に回答いたします

OPA820IDR の詳細情報

型番	OPA820IDR
メーカー	TI
データシート
Amplifier Type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB)	-23 uA
Bias Current-Max (IIB) @25C	16 uA
Common-mode Reject Ratio-Min	76 dB
Common-mode Reject Ratio-Nom	85 dB
Input Offset Voltage-Max	1100 uV
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e4
Length	4.905 mm
Mfr Name	TEXAS INSTRUMENTS INC
Mfr P/N	OPA820IDRG4
Moisture Sensitivity Level	2
Neg Supply Voltage Limit-Max	-6.5 V
Neg Supply Voltage-Nom (Vsup)	-5 V
New Category	Operational Amplifiers
New Part Type	AMPLIFIERS
Number of Functions	1
Number of Terminals	8
Old Category	Audio/Video Amplifiers
Old Part Type	CONSUMER_ICS
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Part Objectid	2084636684
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	1.75 mm
Slew Rate-Nom	240 V/us
Sub Category	Operational Amplifier
Supply Current-Max	5.75 mA
Supply Voltage Limit-Max	6.5 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Unity Gain BW-Nom	280000 kHz
Width	3.895 mm
