LMZ10501SILT

Name: LMZ10501SILT
Brand: TI
SKU: 220200134-0000-0000-0000

LMZ10501SILT - TI の商品詳細ページです。

２営業日以内に回答いたします

LMZ10501SILT の詳細情報

型番	LMZ10501SILT
メーカー	TI
Additional Feature	ADJUSTABLE OUTPUT MODE FROM 0.6 TO 3.6V
Analog IC - Other Type	SWITCHING REGULATOR
Control Mode	CURRENT-MODE
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	5.5 V
Input Voltage-Min	2.7 V
Input Voltage-Nom	3.6 V
JESD-30 Code	R-PDSO-N8
JESD-609 Code	e4
Length	3 mm
Moisture Sensitivity Level	3
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	1 A
Output Voltage-Max	3.6 V
Output Voltage-Min	0.6 V
Package Body Material	PLASTIC/EPOXY
Package Code	HTSON
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, HEAT SINK/SLUG, THIN PROFILE Meter
Peak Reflow Temperature (Cel)	260
Seated Height-Max	1.5 mm
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	2250 kHz
Temperature Grade	AUTOMOTIVE
Terminal Finish	Nickel/Gold (Ni/Au)
Terminal Form	NO LEAD
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	2.6 mm
