LMH6624MA/NOPB の詳細情報

  • 仕様・詳細
  • メーカー情報
型番LMH6624MA/NOPB
メーカーTI
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB) 20 uA
Bandwidth (3dB)-Nom 90 MHz
Bias Current-Max (IIB) @25C 20 uA
Common-mode Reject Ratio-Min 87 dB
Common-mode Reject Ratio-Nom 90 dB
Frequency Compensation YES
Input Offset Current-Max (IIO) 1.5 uA
Input Offset Voltage-Max 500 uV
JESD-30 Code R-PDSO-G8
JESD-609 Code e3
Length 4.9 mm
Low-Bias NO
Low-Offset YES
Micropower NO
Moisture Sensitivity Level 1
Neg Supply Voltage Limit-Max -6.6 V
Neg Supply Voltage-Nom (Vsup) -2.5 V
Number of Functions 1
Number of Terminals 8
Operating Temperature-Max 125 Cel
Operating Temperature-Min -40 Cel
Package Body Material PLASTIC/EPOXY
Package Code SOP
Package Equivalence Code SOP8,.25
Package Shape RECTANGULAR
Package Style SMALL OUTLINE Meter
Packing Method RAIL
Peak Reflow Temperature (Cel) 260
Power NO
Power Supplies +-2.5/+-6/+5/+12 V
Programmable Power NO
Qualification Status Not Qualified
Seated Height-Max 1.75 mm
Slew Rate-Nom 300 V/us
Sub Category Operational Amplifier
Supply Current-Max 16 mA
Supply Voltage Limit-Max 6.6 V
Supply Voltage-Nom (Vsup) 2.5 V
Surface Mount YES
Technology BIPOLAR
Temperature Grade AUTOMOTIVE
Terminal Finish Matte Tin (Sn)
Terminal Form GULL WING
Terminal Pitch 1.27 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 40
Unity Gain BW-Nom 1800000 kHz
Voltage Gain-Min 3160
