LM828M5X/NOPB

Name: LM828M5X/NOPB
Brand: TI
SKU: 220223125-0000-0000-0000

LM828M5X/NOPB - TI の商品詳細ページです。

２営業日以内に回答いたします

LM828M5X/NOPB の詳細情報

型番	LM828M5X/NOPB
メーカー	TI
Analog IC - Other Type	SWITCHED CAPACITOR CONVERTER
Input Voltage-Max	5.5 V
Input Voltage-Min	1.8 V
Input Voltage-Nom	5 V
JESD-30 Code	R-PDSO-G5
JESD-609 Code	e3
Length	2.92 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	5
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	0.005 A
Output Voltage-Max	-1.8 V
Output Voltage-Min	-5.5 V
Output Voltage-Nom	-5.5 V
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Equivalence Code	TSOP5/6,.11,37
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	1.22 mm
Sub Category	Other Analog ICs
Surface Mount	YES
Switcher Configuration	DOUBLER INVERTER
Switching Frequency-Max	28 kHz
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
Width	1.6 mm
