LM741CH/NOPB Ti

LM741CH/NOPB - TI の商品詳細ページです。

1
LM741CH/NOPB
  • LM741CH/NOPB
  • LM741CH/NOPB
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • no_image
  • 個
２営業日以内に回答いたします
この商品のお問い合わせ

LM741CH/NOPB の詳細情報

  • 仕様・詳細
  • メーカー情報
型番LM741CH/NOPB
メーカーTI
Amplifier Type OPERATIONAL AMPLIFIER
Architecture VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB) 0.8 uA
Bias Current-Max (IIB) @25C 0.5 uA
Common-mode Reject Ratio-Min 70 dB
Common-mode Reject Ratio-Nom 90 dB
Frequency Compensation YES
Input Offset Current-Max (IIO) 0.2 uA
Input Offset Voltage-Max 6000 uV
JESD-30 Code O-MBCY-W8
JESD-609 Code e1
Low-Bias NO
Low-Offset NO
Micropower NO
Moisture Sensitivity Level 1
Neg Supply Voltage Limit-Max -18 V
Neg Supply Voltage-Nom (Vsup) -15 V
Number of Functions 1
Number of Terminals 8
Operating Temperature-Max 70 Cel
Operating Temperature-Min 0 Cel
Package Body Material METAL
Package Code TO-99
Package Equivalence Code CAN8,.2
Package Shape ROUND
Package Style CYLINDRICAL Meter
Peak Reflow Temperature (Cel) 260
Power NO
Power Supplies +-15 V
Programmable Power NO
Qualification Status Not Qualified
Slew Rate-Nom 0.5 V/us
Sub Category Operational Amplifier
Supply Current-Max 2.8 mA
Supply Voltage Limit-Max 18 V
Supply Voltage-Nom (Vsup) 15 V
Surface Mount NO
Technology BIPOLAR
Temperature Grade COMMERCIAL
Terminal Finish Tin/Silver/Copper (Sn/Ag/Cu)
Terminal Form WIRE
Terminal Position BOTTOM
Time@Peak Reflow Temperature-Max (s) 40
Unity Gain BW-Nom 437 kHz
Voltage Gain-Min 15000
Wideband NO
会社名称Texas Instruments Incorporated.
設立1930
資本金USD 816 million
所在地12500 TI Boulevard Dallas, Texas 75243 USA
URLhttp://www.ti.com/

LM741CH/NOPBのレビュー

LM741CH/NOPB のご注文について
