LM5085MYE/NOPB

Name: LM5085MYE/NOPB
Brand: TI
SKU: 220190385-0000-0000-0000

LM5085MYE/NOPB - TI の商品詳細ページです。

２営業日以内に回答いたします

LM5085MYE/NOPB の詳細情報

型番	LM5085MYE/NOPB
メーカー	TI
Additional Feature	ALSO OPERATES IN ADJUSTABLE MODE FROM 1.25V
Analog IC - Other Type	SWITCHING REGULATOR
Control Mode	VOLTAGE-MODE
Input Voltage-Max	75 V
Input Voltage-Min	4.5 V
Input Voltage-Nom	48 V
JESD-30 Code	S-PDSO-G8
JESD-609 Code	e3
Length	3 mm
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	8
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Current-Max	1.75 A
Output Voltage-Max	75 V
Output Voltage-Min	1.25 V
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP8,.19
Package Shape	SQUARE
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	1.09 mm
Sub Category	Switching Regulator or Controllers
Surface Mount	YES
Switcher Configuration	BUCK
Switching Frequency-Max	1000 kHz
Temperature Grade	AUTOMOTIVE
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
Width	3 mm
