LM337IMP データシート

Name: LM337IMP
Brand: TI
SKU: 220020237-0000-0000-0000

LM337IMP - TI の商品詳細ページです。

２営業日以内に回答いたします

LM337IMP の詳細情報

型番	LM337IMP
メーカー	TI
データシート
Adjustability	ADJUSTABLE
Dropout Voltage1-Nom	2.4 V
Input Voltage-Max	4.2 V
Input Voltage-Min	40 V
Input-Output Voltage Differential-Max	40 V
Input-Output Voltage Differential-Min	3 V
JESD-30 Code	R-PDSO-G4
JESD-609 Code	e0
Length	6.5 mm
Line Regulation-Max (%/V)	0.07
Load Regulation-Max(%)	1.5 %
Moisture Sensitivity Level	1
Number of Functions	1
Number of Outputs	1
Number of Terminals	4
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	-40 Cel
Output Current1-Max	1 A
Output Voltage1-Max	37 V
Output Voltage1-Min	1.2 V
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOT-223
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Regulator Type	ADJUSTABLE NEGATIVE SINGLE OUTPUT STANDARD REGULATOR
Seated Height-Max	1.8 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	BIPOLAR
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	2.3 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
Voltage Tolerance-Max	2.4 %
Width	3.5 mm
