LM311PS データシート

Name: LM311PS
Brand: TI
SKU: 220208091-0000-0000-0000

LM311PS - TI の商品詳細ページです。

２営業日以内に回答いたします

LM311PS の詳細情報

型番	LM311PS
メーカー	TI
データシート
Amplifier Type	COMPARATOR
Average Bias Current-Max (IIB)	0.3 uA
Bias Current-Max (IIB) @25C	0.25 uA
Input Offset Voltage-Max	7500 uV
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e4
Length	6.2 mm
Moisture Sensitivity Level	1
Neg Supply Voltage Limit-Max	-18 V
Neg Supply Voltage-Nom (Vsup)	-15 V
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Output Type	OPEN-COLLECTOR
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.3
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Power Supplies	+-15 V
Qualification Status	Not Qualified
Response Time-Nom	115 ns
Seated Height-Max	2 mm
Sub Category	Comparator
Supply Current-Max	7.5 mA
Supply Voltage Limit-Max	18 V
Supply Voltage-Nom (Vsup)	15 V
Surface Mount	YES
Technology	BIPOLAR
Temperature Grade	COMMERCIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	5.3 mm
