LM2903DR データシート

Name: LM2903DR
Brand: TI
SKU: 220005976-0000-0000-0000

LM2903DR - TI の商品詳細ページです。

２営業日以内に回答いたします

LM2903DR の詳細情報

型番	LM2903DR
メーカー	TI
データシート
Amplifier Type	COMPARATOR
Average Bias Current-Max (IIB)	-0.5 uA
Bias Current-Max (IIB) @25C	0.05 uA
Input Offset Voltage-Max	15000 uV
JESD-30 Code	R-PDIP-T8
JESD-609 Code	e0
Length	4.9 mm
Moisture Sensitivity Level	1
Neg Supply Voltage Limit-Max	-18 V
Neg Supply Voltage-Nom (Vsup)	0 V
Number of Functions	2
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Type	OPEN-COLLECTOR
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	SOP8,.25
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	235
Power Supplies	5 V
Qualification Status	Not Qualified
Response Time-Nom	1300 ns
Seated Height-Max	1.475 mm
Sub Category	Comparator
Supply Current-Max	1 mA
Supply Voltage Limit-Max	18 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	AUTOMOTIVE
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Width	3.9 mm
