LM1117IMPX-ADJ/NOPB

Name: LM1117IMPX-ADJ/NOPB
Brand: TI
SKU: 220189289-0000-0000-0000

LM1117IMPX-ADJ/NOPB - TI の商品詳細ページです。

２営業日以内に回答いたします

LM1117IMPX-ADJ/NOPB の詳細情報

型番	LM1117IMPX-ADJ/NOPB
メーカー	TI
Adjustability	ADJUSTABLE
Dropout Voltage1-Max	1.4 V
Dropout Voltage1-Nom	1.2 V
Input Voltage-Max	15 V
Input Voltage-Min	2.6 V
Input-Output Voltage Differential-Max	13.75 V
Input-Output Voltage Differential-Min	1.5 V
JESD-30 Code	R-PDSO-G4
JESD-609 Code	e3
Length	6.5 mm
Line Regulation-Max (%/V)	0.025
Load Regulation-Max(%)	0.5 %
Mfr Name	ONSEMI
Mfr P/N	LM1117IMPX-ADJNOPB
Moisture Sensitivity Level	1
New Category	Adjustable Positive Single Output LDO Regulators
New Part Type	REGULATORS
Number of Functions	1
Number of Outputs	1
Number of Terminals	4
Old Category	Fixed Positive Single Output LDO Regulators
Old Part Type	REGULATORS
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	-40 Cel
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Current1-Max	0.8 A
Output Voltage1-Max	13.8 V
Output Voltage1-Min	1.25 V
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOT-223
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Part Objectid	7426029451
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Regulator Type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	1.8 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	BIPOLAR
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	2.3 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	40
Voltage Tolerance-Max	3 %
Width	3.56 mm
