LM1085ISX-ADJ

Name: LM1085ISX-ADJ
Brand: TI
SKU: 220208507-0000-0000-0000

LM1085ISX-ADJ - TI の商品詳細ページです。

２営業日以内に回答いたします

LM1085ISX-ADJ の詳細情報

型番	LM1085ISX-ADJ
メーカー	TI
Adjustability	ADJUSTABLE
Dropout Voltage1-Max	1.5 V
Dropout Voltage1-Nom	1.3 V
Input Voltage-Max	29 V
Input Voltage-Min	2.6 V
Input-Output Voltage Differential-Max	15 V
Input-Output Voltage Differential-Min	1.5 V
JESD-30 Code	R-PSSO-G3
JESD-609 Code	e0
Length	10.16 mm
Line Regulation-Max (%/V)	0.2
Load Regulation-Max(%)	0.4 %
Moisture Sensitivity Level	3
Number of Functions	1
Number of Outputs	1
Number of Terminals	3
Operating Temperature, TJ-Max	125 Cel
Operating Temperature, TJ-Min	-40 Cel
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Current1-Max	3 A
Output Voltage1-Max	15 V
Output Voltage1-Min	1.2 V
Package Body Material	PLASTIC/EPOXY
Package Code	TO-263
Package Equivalence Code	SMSIP3H,.55TB
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	235
Qualification Status	Not Qualified
Regulator Type	ADJUSTABLE POSITIVE SINGLE OUTPUT LDO REGULATOR
Seated Height-Max	4.64 mm
Sub Category	Other Regulators
Surface Mount	YES
Technology	BIPOLAR
Terminal Finish	Matte Tin (Sn)
Terminal Form	GULL WING
Terminal Pitch	2.54 mm
Terminal Position	SINGLE
Time@Peak Reflow Temperature-Max (s)	30
Voltage Tolerance-Max	4 %
Width	8.635 mm
