LF356H

Name: LF356H
Brand: TI
SKU: 220207187-0000-0000-0000

LF356H - TI の商品詳細ページです。

２営業日以内に回答いたします

LF356H の詳細情報

型番	LF356H
メーカー	TI
Amplifier Type	OPERATIONAL AMPLIFIER
Architecture	VOLTAGE-FEEDBACK
Average Bias Current-Max (IIB)	0.0002 uA
Bias Current-Max (IIB) @25C	0.0002 uA
Common-mode Reject Ratio-Min	80 dB
Common-mode Reject Ratio-Nom	100 dB
Frequency Compensation	NO
Input Offset Current-Max (IIO)	5.0E-5 uA
Input Offset Voltage-Max	9000 uV
JESD-30 Code	O-MBCY-W8
JESD-609 Code	e0
Low-Bias	YES
Low-Offset	NO
Micropower	NO
Moisture Sensitivity Level	1
Neg Supply Voltage Limit-Max	-18 V
Neg Supply Voltage-Nom (Vsup)	-15 V
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	70 Cel
Operating Temperature-Min	0 Cel
Package Body Material	METAL
Package Code	TO-99
Package Equivalence Code	CAN8,.2
Package Shape	ROUND
Package Style	CYLINDRICAL Meter
Peak Reflow Temperature (Cel)	260
Power	NO
Power Supplies	+-15 V
Programmable Power	NO
Qualification Status	Not Qualified
Screening Level	MIL-STD-883
Slew Rate-Min	4 V/us
Slew Rate-Nom	12 V/us
Sub Category	Operational Amplifier
Supply Current-Max	10 mA
Supply Voltage Limit-Max	18 V
Supply Voltage-Nom (Vsup)	15 V
Surface Mount	NO
Technology	BIPOLAR
Temperature Grade	COMMERCIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	WIRE
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	40
Unity Gain BW-Nom	5000 kHz
Voltage Gain-Min	15000
Wideband	NO
