DS25CP102TSQ データシート

Name: DS25CP102TSQ
Brand: TI
SKU: 140200172-0000-0000-0000

DS25CP102TSQ - TI の商品詳細ページです。

２営業日以内に回答いたします

DS25CP102TSQ の詳細情報

型番	DS25CP102TSQ
メーカー	TI
データシート
Analog IC - Other Type	CROSS POINT SWITCH
JESD-30 Code	S-PQCC-N16
JESD-609 Code	e3
Length	4 mm
Moisture Sensitivity Level	1
Number of Channels	2
Number of Functions	1
Number of Terminals	16
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output	SEPARATE OUTPUT V
Package Body Material	PLASTIC/EPOXY
Package Code	HVQCCN
Package Equivalence Code	LCC16,.16SQ,20
Package Shape	SQUARE
Package Style	CHIP CARRIER Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3.3 V
Qualification Status	Not Qualified
Seated Height-Max	0.75 mm
Sub Category	Multiplexer or Switches
Supply Current-Max (Isup)	90 mA
Supply Voltage-Max (Vsup)	3.6 V
Supply Voltage-Min (Vsup)	3 V
Supply Voltage-Nom (Vsup)	3.3 V
Surface Mount	YES
Switch-off Time-Max	12 ns
Switch-on Time-Max	20000 ns
Switching	BREAK-BEFORE-MAKE V
Temperature Grade	INDUSTRIAL
Terminal Finish	Matte Tin (Sn)
Terminal Form	NO LEAD
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	40
Width	4 mm
