CSD25302Q2 データシート

Name: CSD25302Q2
Brand: TI
SKU: 130400507-0000-0000-0000

CSD25302Q2 - TI の商品詳細ページです。

２営業日以内に回答いたします

CSD25302Q2 の詳細情報

型番	CSD25302Q2
メーカー	TI
データシート
Additional Feature	AVALANCHE RATED
Case Connection	SOURCE
Configuration	SINGLE WITH BUILT-IN DIODE
DS Breakdown Voltage-Min	20 V
Drain Current-Max (Abs) (ID)	5 A
Drain Current-Max (ID)	5 A
Drain-source On Resistance-Max	0.092 ohm
FET Technology	METAL-OXIDE SEMICONDUCTOR
JESD-30 Code	S-PDSO-N6
JESD-609 Code	e3
Moisture Sensitivity Level	1
Number of Elements	1
Number of Terminals	6
Operating Mode	ENHANCEMENT MODE
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	SQUARE
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Polarity/Channel Type	P-CHANNEL
Power Dissipation-Max (Abs)	2.4 W
Pulsed Drain Current-Max (IDM)	20 A
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	YES
Terminal Finish	Matte Tin (Sn)
Terminal Form	NO LEAD
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Transistor Application	SWITCHING
Transistor Element Material	SILICON
