CSD23201W10 データシート

Name: CSD23201W10
Brand: TI
SKU: 130399575-0000-0000-0000

CSD23201W10 - TI の商品詳細ページです。

２営業日以内に回答いたします

CSD23201W10 の詳細情報

型番	CSD23201W10
メーカー	TI
データシート
Configuration	SINGLE WITH BUILT-IN DIODE AND RESISTOR
DS Breakdown Voltage-Min	12 V
Drain Current-Max (Abs) (ID)	1.1 A
Drain Current-Max (ID)	2.2 A
Drain-source On Resistance-Max	0.138 ohm
FET Technology	METAL-OXIDE SEMICONDUCTOR
Feedback Cap-Max (Crss)	42 pF
JESD-30 Code	S-PBGA-B4
JESD-609 Code	e1
Moisture Sensitivity Level	1
Number of Elements	1
Number of Terminals	4
Operating Mode	ENHANCEMENT MODE
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	SQUARE
Package Style	GRID ARRAY Meter
Peak Reflow Temperature (Cel)	260
Polarity/Channel Type	P-CHANNEL
Power Dissipation-Max (Abs)	1 W
Qualification Status	Not Qualified
Sub Category	Other Transistors
Surface Mount	YES
Terminal Finish	Tin/Silver/Copper (Sn/Ag/Cu)
Terminal Form	BALL
Terminal Position	BOTTOM
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Transistor Application	SWITCHING
Transistor Element Material	SILICON
