CD4046BE データシート

Name: CD4046BE
Brand: TI
SKU: 130005357-0000-0000-0000

CD4046BE - TI の商品詳細ページです。

No Image

２営業日以内に回答いたします

CMOS標準ロジックIC|PLL(電圧制御発振器+位相比較器) | 16ピン|パーッケージ：PDIP

CD4046BE の詳細情報

型番	CD4046BE
メーカー	TI
種別	CMOS標準ロジックIC
データシート
Analog IC - Other Type	PHASE LOCKED LOOP
JESD-30 Code	R-PDIP-T16
JESD-609 Code	e0
Length	19.305 mm
Number of Functions	1
Number of Terminals	16
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-55 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	DIP
Package Equivalence Code	DIP16,.3
Package Shape	RECTANGULAR
Package Style	IN-LINE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	5/15 V
Qualification Status	Not Qualified
Seated Height-Max	5.08 mm
Sub Category	PLL or Frequency Synthesis Circuits
Supply Current-Max (Isup)	3 mA
Supply Voltage-Max (Vsup)	18 V
Supply Voltage-Min (Vsup)	3 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	NO
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	THROUGH-HOLE
Terminal Pitch	2.54 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	7.62 mm
