CD40109BQNSRQ1 データシート

Name: CD40109BQNSRQ1
Brand: TI
SKU: 130404168-0000-0000-0000

CD40109BQNSRQ1 - TI の商品詳細ページです。

２営業日以内に回答いたします

CMOS標準ロジックIC

CD40109BQNSRQ1 の詳細情報

型番	CD40109BQNSRQ1
メーカー	TI
種別	CMOS標準ロジックIC
データシート
Control Type	ENABLE HIGH
Count Direction	UNIDIRECTIONAL
Family	4000/14000/40000
JESD-30 Code	R-PDSO-G14
JESD-609 Code	e4
Length	10.2 mm
Load Capacitance (CL)	50 pF
Logic IC Type	BUS DRIVER
Max I(ol)	0.0068 Amp
Moisture Sensitivity Level	1
Number of Bits	1
Number of Functions	4
Number of Ports	2
Number of Terminals	14
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Output Characteristics	3-STATE
Output Polarity	TRUE
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Packing Method	TR
Peak Reflow Temperature (Cel)	260
Power Supply Current-Max (ICC)	0.12 mA
Prop. Delay@Nom-Sup	600 ns
Propagation Delay (tpd)	600 ns
Screening Level	AEC-Q100
Seated Height-Max	2 mm
Supply Voltage-Max (Vsup)	18 V
Supply Voltage-Min (Vsup)	3 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	AUTOMOTIVE
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Translation	N/A
Width	5.3 mm
