BQ24032RHLR データシート

Name: BQ24032RHLR
Brand: TI
SKU: 120007180-0000-0000-0000

BQ24032RHLR - TI の商品詳細ページです。

２営業日以内に回答いたします

BQ24032RHLR の詳細情報

型番	BQ24032RHLR
メーカー	TI
データシート
Adjustable Threshold	NO
Analog IC - Other Type	POWER SUPPLY MANAGEMENT CIRCUIT
JESD-30 Code	R-PQCC-N20
Length	4.5 mm
Number of Channels	1
Number of Functions	1
Number of Terminals	20
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	HVQCCN
Package Equivalence Code	LCC20/24,.14X.18,20
Package Shape	RECTANGULAR
Package Style	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	4.3/16 V
Qualification Status	Not Qualified
Seated Height-Max	1 mm
Sub Category	Power Management Circuits
Supply Current-Max (Isup)	2 mA
Supply Voltage-Max (Vsup)	16 V
Supply Voltage-Min (Vsup)	4.35 V
Surface Mount	YES
Temperature Grade	AUTOMOTIVE
Terminal Form	NO LEAD
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	3.5 mm
