AM26LV32EMDREP データシート

Name: AM26LV32EMDREP
Brand: TI
SKU: 110148128-0000-0000-0000

AM26LV32EMDREP - TI の商品詳細ページです。

２営業日以内に回答いたします

AM26LV32EMDREP の詳細情報

型番	AM26LV32EMDREP
メーカー	TI
データシート
Differential Output	NO
Input Characteristics	DIFFERENTIAL SCHMITT TRIGGER
Interface IC Type	LINE RECEIVER
Interface Standard	EIA-422-B; TIA-422-B; V.11
JESD-30 Code	R-PDSO-G16
JESD-609 Code	e4
Length	9.9 mm
Moisture Sensitivity Level	1
Number of Functions	4
Number of Terminals	16
Operating Temperature-Max	125 Cel
Operating Temperature-Min	-55 Cel
Output Low Current-Max	0.005 Amp
Output Polarity	TRUE
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP16,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Qualification Status	Not Qualified
Receive Delay-Max	26 ns
Receiver Number of Bits	4
Seated Height-Max	1.75 mm
Supply Current-Max	17 mA
Supply Voltage-Max	3.6 V
Supply Voltage-Min	3 V
Supply Voltage-Nom	3.3 V
Supply Voltage1-Max	3.6 V
Supply Voltage1-Min	3 V
Supply Voltage1-Nom	3.3 V
Surface Mount	YES
Temperature Grade	MILITARY
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Width	3.9 mm
