ADS1243IPWT データシート

Name: ADS1243IPWT
Brand: TI
SKU: 110026492-0000-0000-0000

ADS1243IPWT - TI の商品詳細ページです。

２営業日以内に回答いたします

ADS1243IPWT の詳細情報

型番	ADS1243IPWT
メーカー	TI
データシート
Analog Input Voltage-Max	1.25 V
Analog Input Voltage-Min	0 V
Converter Type	ADC, DELTA-SIGMA
JESD-30 Code	R-PDSO-G20
JESD-609 Code	e4
Length	6.5 mm
Linearity Error-Max (EL)	0.0015 %
Moisture Sensitivity Level	1
Number of Analog In Channels	8
Number of Bits	24
Number of Functions	1
Number of Terminals	20
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Bit Code	BINARY
Output Format	SERIAL
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP20,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3/5 V
Qualification Status	Not Qualified
Sample Rate	1.5E-5 MHz
Seated Height-Max	1.2 mm
Sub Category	Other Converters
Supply Current-Max	1.325 mA
Supply Voltage-Min	2.7 V
Supply Voltage-Nom	3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Nickel/Palladium/Gold (Ni/Pd/Au)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	4.4 mm
