5962-8861901XA の詳細情報

  • 仕様・詳細
  • メーカー情報
型番5962-8861901XA
メーカーTI
Address Bus Width 16
Barrel Shifter YES
Bit Size 16
Boundary Scan NO
Clock Frequency-Max 40 MHz
External Data Bus Width 16
Format FIXED POINT
Integrated Cache NO
Internal Bus Architecture MULTIPLE
JESD-30 Code S-CPGA-P68
JESD-609 Code e0
Length 24.38 mm
Low Power Mode NO
Number of DMA Channels 0
Number of External Interrupts 3
Number of Serial I/Os 1
Number of Terminals 68
Number of Timers 1
On Chip Data RAM Width 16
On Chip Program ROM Width 16
Operating Temperature-Max 125 Cel
Operating Temperature-Min -55 Cel
Package Body Material CERAMIC, METAL-SEALED COFIRED
Package Code PGA
Package Equivalence Code PGA68,11X11
Package Shape SQUARE
Package Style GRID ARRAY Meter
Peak Reflow Temperature (Cel) NOT SPECIFIED
Power Supplies 5 V
Qualification Status Not Qualified
RAM (words) 544
ROM (words) 65536
ROM Programmability MROM
Screening Level MIL-STD-883
Seated Height-Max 2.23 mm
Sub Category Digital Signal Processors
Supply Current-Max 185 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 4.5 V
Supply Voltage-Nom 5 V
Surface Mount NO
Technology CMOS
Temperature Grade MILITARY
Terminal Finish TIN LEAD
Terminal Form PIN/PEG
Terminal Pitch 2.54 mm
Terminal Position PERPENDICULAR
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Width 24.38 mm
uPs/uCs/Peripheral ICs Type DIGITAL SIGNAL PROCESSOR, OTHER
