UPD4991AGS-A データシート

Name: UPD4991AGS-A
Brand: RENESAS
SKU: 310095509-0000-0000-0000

UPD4991AGS-A - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

鉛フリー品

UPD4991AGS-A の詳細情報

型番	UPD4991AGS-A
メーカー	RENESAS
データシート
Clock Frequency-Max	0.032 MHz
External Data Bus Width	4
Information Access Method	PARALLEL, DIRECT ADDRESS
Interrupt Capability	Y
JESD-30 Code	R-PDSO-G20
JESD-609 Code	e6
Length	12.7 mm
Number of Bits	1
Number of Terminals	20
Number of Timers	1
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP20,.3
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	5 V
Qualification Status	Not Qualified
Seated Height-Max	1.8 mm
Sub Category	Timer or RTC
Supply Voltage-Max	5.5 V
Supply Voltage-Min	2 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN BISMUTH
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time-Min	SECONDS
Time@Peak Reflow Temperature-Max (s)	10
Volatile	YES
Width	5.6 mm
uPs/uCs/Peripheral ICs Type	TIMER, REAL TIME CLOCK
