UPD168110MA-6A5-A データシート

Name: UPD168110MA-6A5-A
Brand: RENESAS
SKU: 310094827-0000-0000-0000

UPD168110MA-6A5-A - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

UPD168110MA-6A5-A の詳細情報

型番	UPD168110MA-6A5-A
メーカー	RENESAS
データシート
Analog IC - Other Type	STEPPER MOTOR CONTROLLER
JESD-30 Code	R-PDSO-G24
JESD-609 Code	e6
Length	6.65 mm
Number of Functions	1
Number of Terminals	24
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-10 Cel
Output Current-Max	0.7 A
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP24,.25,20
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	3 V
Qualification Status	Not Qualified
Seated Height-Max	1.2 mm
Sub Category	Motion Control Electronics
Supply Voltage-Max (Vsup)	3.6 V
Supply Voltage-Min (Vsup)	2.7 V
Supply Voltage-Nom (Vsup)	3 V
Surface Mount	YES
Technology	MOS
Temperature Grade	COMMERCIAL EXTENDED
Terminal Finish	TIN BISMUTH
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	10
Width	4.4 mm
