UPD16312GB-3B4 データシート

Name: UPD16312GB-3B4
Brand: RENESAS
SKU: 310099814-0000-0000-0000

UPD16312GB-3B4 - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

UPD16312GB-3B4 の詳細情報

型番	UPD16312GB-3B4
メーカー	RENESAS
データシート
Additional Feature	IT ALSO REQUIRES -35V SUPPLY
Address Bus Width	0
Clock Frequency-Max	1 MHz
Display Configuration	4 X 16 SEGMENTS
External Data Bus Width	0
JESD-30 Code	S-PQFP-G44
JESD-609 Code	e0
Length	10 mm
Number of Terminals	44
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-20 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	QFP
Package Shape	SQUARE
Package Style	FLATPACK Meter
Peak Reflow Temperature (Cel)	235
Qualification Status	Not Qualified
Seated Height-Max	3 mm
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	MOS
Temperature Grade	COMMERCIAL
Terminal Finish	TIN LEAD
Terminal Form	GULL WING
Terminal Pitch	0.8 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	30
Width	10 mm
uPs/uCs/Peripheral ICs Type	DISPLAY CONTROLLER, FLUORESCENT
