UPC1093T データシート

Name: UPC1093T
Brand: RENESAS
SKU: 310093357-0000-0000-0000

UPC1093T - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

UPC1093T の詳細情報

型番	UPC1093T
メーカー	RENESAS
カテゴリ	レギュレータ
データシート
Analog IC - Other Type	TWO TERMINAL VOLTAGE REFERENCE
JESD-30 Code	R-PDSO-F3
JESD-609 Code	e0
Length	2.9 mm
Number of Functions	1
Number of Outputs	1
Number of Terminals	3
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-20 Cel
Output Current-Max	0.1 A
Output Voltage-Max	36 V
Output Voltage-Min	2.495 V
Output Voltage-Nom	2.495 V
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Equivalence Code	TO-243
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	235
Qualification Status	Not Qualified
Seated Height-Max	1.4 mm
Sub Category	Voltage References
Surface Mount	YES
Technology	BIPOLAR
Temp Coef of Voltage-Max	100 ppm/Cel
Temperature Grade	OTHER
Terminal Finish	MATTE TIN
Terminal Form	FLAT
Terminal Pitch	0.95 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	30
Trim/Adjustable Output	YES V
Width	1.5 mm
