UPA1970TE の詳細情報

型番	UPA1970TE
メーカー	RENESAS
カテゴリ	スイッチ-その他IC
データシート
Configuration	SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE
DS Breakdown Voltage-Min	20 V
Drain Current-Max (Abs) (ID)	2.2 A
Drain Current-Max (ID)	2.2 A
Drain-source On Resistance-Max	0.107 ohm
FET Technology	METAL-OXIDE SEMICONDUCTOR
JESD-30 Code	R-PDSO-G6
JESD-609 Code	e0
Number of Elements	2
Number of Terminals	6
Operating Mode	ENHANCEMENT MODE
Operating Temperature-Max	150 Cel
Package Body Material	PLASTIC/EPOXY
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Polarity/Channel Type	N-CHANNEL
Power Dissipation-Max (Abs)	1.15 W
Pulsed Drain Current-Max (IDM)	8.8 A
Qualification Status	Not Qualified
Sub Category	FET General Purpose Power
Surface Mount	YES
Terminal Finish	MATTE TIN
Terminal Form	GULL WING
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	10
Transistor Application	SWITCHING
Transistor Element Material	SILICON
