RAA230409GFT データシート

Name: RAA230409GFT
Brand: RENESAS
SKU: 280409835-0000-0000-0000

RAA230409GFT - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

RAA230409GFT の詳細情報

型番	RAA230409GFT
メーカー	RENESAS
カテゴリ	その他-その他IC
データシート
Analog IC - Other Type	ANALOG CIRCUIT
JESD-30 Code	S-PQFP-G32
Length	7 mm
Moisture Sensitivity Level	3
Number of Functions	1
Number of Terminals	32
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	HTQFP
Package Shape	SQUARE
Package Style	FLATPACK, HEAT SINK/SLUG, THIN PROFILE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Seated Height-Max	1.2 mm
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	2.5 V
Supply Voltage-Nom (Vsup)	5 V
Surface Mount	YES
Temperature Grade	INDUSTRIAL
Terminal Form	GULL WING
Terminal Pitch	0.8 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	7 mm
