R5F61657CN35FTV データシート

Name: R5F61657CN35FTV
Brand: RENESAS
SKU: 280384682-0000-0000-0000

R5F61657CN35FTV - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

R5F61657CN35FTV の詳細情報

型番	R5F61657CN35FTV
メーカー	RENESAS
データシート
ADC Channels	YES
Address Bus Width	24
Bit Size	32
Clock Frequency-Max	35 MHz
DAC Channels	YES
DMA Channels	YES
External Data Bus Width	16
JESD-30 Code	S-PQFP-G120
Length	14 mm
Number of I/O Lines	90
Number of Terminals	120
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-20 Cel
PWM Channels	YES
Package Body Material	PLASTIC/EPOXY
Package Code	TFQFP
Package Shape	SQUARE
Package Style	FLATPACK, THIN PROFILE, FINE PITCH Meter
ROM Programmability	FLASH
Seated Height-Max	1.2 mm
Speed	35 rpm
Supply Voltage-Max	3.6 V
Supply Voltage-Min	3 V
Supply Voltage-Nom	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL EXTENDED
Terminal Form	GULL WING
Terminal Pitch	0.4 mm
Terminal Position	QUAD
Width	14 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
