R5F100ACASP#V0 データシート

Name: R5F100ACASP#V0
Brand: RENESAS
SKU: 280395407-0000-0000-0000

R5F100ACASP#V0 - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

R5F100ACASP#V0 の詳細情報

型番	R5F100ACASP#V0
メーカー	RENESAS
データシート
A/D Converters	8-Ch 10-Bit
ADC Channels	YES
Additional Feature	IT ALSO OPERATES AT 4MHZ @1.6V MIN SUPPLY @ LOW-VOLTAGE MAIN MODE
Address Bus Width	0
Bit Size	16
Clock Frequency-Max	20 MHz
Connectivity	CSI(3), I2C(4), LIN, UART(3)
DAC Channels	NO
DMA Channels	YES
Data EEPROM Size	4K
External Data Bus Width	0
JESD-30 Code	R-PDSO-G30
Length	9.85 mm
Moisture Sensitivity Level	3
Number of I/O Lines	26
Number of Terminals	30
On Chip Program ROM Width	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
PWM Channels	YES
Package Body Material	PLASTIC/EPOXY
Package Code	LSSOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, LOW PROFILE, SHRINK PITCH Meter
Peripherals	BUZZER(2), DMA(2), POR, PWM, RTC, TIMER(9), WDT
RAM (bytes)	2048
ROM (words)	32768
ROM Programmability	FLASH
Seated Height-Max	1.4 mm
Speed	32 rpm
Supply Voltage-Max	5.5 V
Supply Voltage-Min	2.7 V
Supply Voltage-Nom	3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Width	6.1 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
