R5F1007EANA#U0 データシート

Name: R5F1007EANA#U0
Brand: RENESAS
SKU: 280389783-0000-0000-0000

R5F1007EANA#U0 - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

R5F1007EANA#U0 の詳細情報

型番	R5F1007EANA#U0
メーカー	RENESAS
データシート
A/D Converters	6-Ch 10-Bit
ADC Channels	YES
Additional Feature	IT ALSO OPERATES AT 4MHZ @1.6V MIN SUPPLY @ LOW-VOLTAGE MAIN MODE
Address Bus Width	0
Bit Size	16
Clock Frequency-Max	20 MHz
Connectivity	CSI(2), I2C(3), UART(2)
DAC Channels	NO
DMA Channels	YES
Data EEPROM Size	4K
External Data Bus Width	0
JESD-30 Code	S-PQCC-N24
Length	4 mm
Number of I/O Lines	20
Number of Terminals	24
On Chip Program ROM Width	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
PWM Channels	YES
Package Body Material	PLASTIC/EPOXY
Package Code	HVQCCN
Package Shape	SQUARE
Package Style	CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Peripherals	BUZZER, DMA(2), POR, PWM, RTC, TIMER(9), WDT
RAM (bytes)	4096
ROM (words)	65536
ROM Programmability	FLASH
Seated Height-Max	0.8 mm
Speed	32 rpm
Supply Voltage-Max	5.5 V
Supply Voltage-Min	2.7 V
Supply Voltage-Nom	3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Form	NO LEAD
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	4 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
