PS2501AL-1-F3-A データシート

Name: PS2501AL-1-F3-A
Brand: RENESAS
SKU: 260236864-0000-0000-0000

PS2501AL-1-F3-A - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

PS2501AL-1-F3-A の詳細情報

型番	PS2501AL-1-F3-A
メーカー	RENESAS
データシート
Additional Feature	UL APPROVED
Coll-emtr Bkdn Voltage-Min	70 V
Configuration	SINGLE
Current Transfer Ratio-Min	50 %
Current Transfer Ratio-Nom	50 %
Dark Current-Max	100 nA
Forward Current-Max	0.03 A
Forward Voltage-Max	1.4 V
Isolation Voltage-Max	5000 V
JESD-609 Code	e0
Mounting Feature	SURFACE MOUNT
Number of Elements	1
On-State Current-Max	0.03 A
Operating Temperature-Max	100 Cel
Operating Temperature-Min	-55 Cel
Optoelectronic Device Type	TRANSISTOR OUTPUT OPTOCOUPLER
Power Dissipation-Max	0.15 W
Sub Category	Optocoupler - Transistor Outputs
Terminal Finish	TIN BISMUTH/NICKEL PALLADIUM GOLD
