M66596FP データシート

Name: M66596FP
Brand: RENESAS
SKU: 230375904-0000-0000-0000

M66596FP - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

M66596FP の詳細情報

型番	M66596FP
メーカー	RENESAS
データシート
Address Bus Width	6
Clock Frequency-Max	48 MHz
External Data Bus Width	16
JESD-30 Code	S-PQFP-G64
Moisture Sensitivity Level	1
Number of Terminals	64
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-20 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	FQFP
Package Equivalence Code	QFP64,.47SQ,20
Package Shape	SQUARE
Package Style	FLATPACK, FINE PITCH Meter
Peak Reflow Temperature (Cel)	225
Power Supplies	1.5,1.8/3.3 V
Qualification Status	Not Qualified
Sub Category	Bus Controllers
Supply Voltage-Max	1.65 V
Supply Voltage-Min	1.35 V
Supply Voltage-Nom	1.5 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	OTHER
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
uPs/uCs/Peripheral ICs Type	BUS CONTROLLER, UNIVERSAL SERIAL BUS
