M66011FP データシート

Name: M66011FP
Brand: RENESAS
SKU: 230034224-0000-0000-0000

M66011FP - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

M66011FP の詳細情報

型番	M66011FP
メーカー	RENESAS
データシート
Address Bus Width	2
Boundary Scan	NO
Clock Frequency-Max	8.33 MHz
Communication Protocol	ASYNC, BIT
Data Encoding/Decoding Method	NRZ
External Data Bus Width	8
JESD-30 Code	R-PDSO-G24
JESD-609 Code	e0
Length	15.02 mm
Low Power Mode	NO
Number of DMA Channels	0
Number of I/O Lines	0
Number of Serial I/Os	1
Number of Terminals	24
On Chip Data RAM Width	0
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-20 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Qualification Status	Not Qualified
RAM (words)	0
Seated Height-Max	2.1 mm
Supply Voltage-Max	5.5 V
Supply Voltage-Min	4.5 V
Supply Voltage-Nom	5 V
Surface Mount	YES
Technology	MOS
Temperature Grade	COMMERCIAL EXTENDED
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Width	5.3 mm
uPs/uCs/Peripheral ICs Type	SERIAL IO/COMMUNICATION CONTROLLER, SERIAL
