M5237L データシート

Name: M5237L
Brand: RENESAS
SKU: 230726523-0000-0000-0000

M5237L - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

M5237L の詳細情報

型番	M5237L
メーカー	RENESAS
データシート
Adjustability	ADJUSTABLE
JESD-30 Code	O-PBCY-T3
JESD-609 Code	e0
Line Regulation-Max (%/V)	0.1
Load Regulation-Max(%)	0.1 %
Number of Functions	1
Number of Outputs	1
Number of Terminals	3
Operating Temperature, TJ-Max	75 Cel
Operating Temperature, TJ-Min	-20 Cel
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-20 Cel
Output Current1-Max	0.2 A
Output Voltage1-Max	33 V
Output Voltage1-Min	1.5 V
Package Body Material	PLASTIC/EPOXY
Package Code	TO-92
Package Equivalence Code	SIP3,.05,50
Package Shape	ROUND
Package Style	CYLINDRICAL Meter
Qualification Status	Not Qualified
Regulator Type	ADJUSTABLE POSITIVE SINGLE OUTPUT STANDARD REGULATOR
Sub Category	Other Regulators
Surface Mount	NO
Technology	BIPOLAR
Terminal Finish	TIN COPPER
Terminal Form	THROUGH-HOLE
Terminal Pitch	1.27 mm
Terminal Position	BOTTOM
