M51995AFP#CF0J データシート

Name: M51995AFP#CF0J
Brand: RENESAS
SKU: 230093593-0000-0000-0000

M51995AFP#CF0J - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

M51995AFP#CF0J の詳細情報

型番	M51995AFP#CF0J
メーカー	RENESAS
データシート
Analog IC - Other Type	SWITCHING CONTROLLER
Control Technique	PULSE WIDTH MODULATION
Input Voltage-Max	36 V
Input Voltage-Min	12 V
Input Voltage-Nom	18 V
JESD-30 Code	R-PDSO-G20
Length	12.6 mm
Number of Functions	1
Number of Terminals	20
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-30 Cel
Output Current-Max	2 A
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Seated Height-Max	2.1 mm
Surface Mount	YES
Switcher Configuration	SINGLE
Switching Frequency-Max	500 kHz
Temperature Grade	COMMERCIAL EXTENDED
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	20
Width	5.3 mm
