M51953BFP データシート

Name: M51953BFP
Brand: RENESAS
SKU: 230026246-0000-0000-0000

M51953BFP - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

M51953BFP の詳細情報

型番	M51953BFP
メーカー	RENESAS
データシート
Additional Feature	DETECTION THRESHOLD VOLTAGE IS 4.25V
Adjustable Threshold	NO
Analog IC - Other Type	POWER SUPPLY SUPPORT CIRCUIT
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e0
Length	4.85 mm
Number of Channels	1
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-30 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	SOP
Package Equivalence Code	SOP8,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE Meter
Power Supplies	2/17 V
Qualification Status	Not Qualified
Seated Height-Max	1.9 mm
Sub Category	Power Management Circuits
Supply Current-Max (Isup)	0.63 mA
Supply Voltage-Max (Vsup)	17 V
Supply Voltage-Min (Vsup)	2 V
Supply Voltage-Nom (Vsup)	4 V
Surface Mount	YES
Temperature Grade	OTHER
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	1.27 mm
Terminal Position	DUAL
Threshold Voltage-Nom	+4.25V V
Width	4.4 mm
