HSK120 データシート

Name: HSK120
Brand: RENESAS
SKU: 180155031-0000-0000-0000

HSK120 - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

HSK120 の詳細情報

型番	HSK120
メーカー	RENESAS
データシート
Case Connection	ISOLATED
Configuration	SINGLE
Diode Element Material	SILICON
Diode Type	RECTIFIER DIODE
Forward Voltage-Max (VF)	0.8 V
JESD-30 Code	O-LELF-R2
JESD-609 Code	e0
Moisture Sensitivity Level	1
Non-rep Pk Forward Current-Max	4 A
Number of Elements	1
Number of Phases	1
Number of Terminals	2
Operating Temperature-Max	175 Cel
Output Current-Max	0.15 A
Package Body Material	GLASS
Package Shape	ROUND
Package Style	LONG FORM Meter
Peak Reflow Temperature (Cel)	260
Qualification Status	Not Qualified
Rep Pk Reverse Voltage-Max	70 V
Reverse Current-Max	0.1 uA
Reverse Recovery Time-Max	0.003 us
Sub Category	Rectifier Diodes
Surface Mount	YES
Terminal Finish	Tin/Bismuth (Sn/Bi)
Terminal Form	WRAP AROUND
Terminal Position	END
Time@Peak Reflow Temperature-Max (s)	20
