HD74LV2G123AUSE データシート

Name: HD74LV2G123AUSE
Brand: RENESAS
SKU: 180014834-0000-0000-0000

HD74LV2G123AUSE - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

CMOS標準ロジックIC

HD74LV2G123AUSE の詳細情報

型番	HD74LV2G123AUSE
メーカー	RENESAS
種別	CMOS標準ロジックIC
データシート
Family	LV/LV-A/LVX/H
JESD-30 Code	R-PDSO-G8
JESD-609 Code	e0
Length	2.3 mm
Logic IC Type	MONOSTABLE MULTIVIBRATOR
Moisture Sensitivity Level	1
Number of Data/Clock Inputs	2
Number of Functions	1
Number of Terminals	8
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Output Characteristics	3-STATE
Package Body Material	PLASTIC/EPOXY
Package Code	VSSOP
Package Equivalence Code	TSSOP8,.12,20
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, VERY THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	1.8/5 V
Propagation Delay (tpd)	82 ns
Qualification Status	Not Qualified
Seated Height-Max	0.9 mm
Sub Category	Prescaler/Multivibrators
Supply Voltage-Max (Vsup)	5.5 V
Supply Voltage-Min (Vsup)	1.65 V
Supply Voltage-Nom (Vsup)	1.8 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	20
Width	2 mm
