HD74HC4066TELL データシート

Name: HD74HC4066TELL
Brand: RENESAS
SKU: 180049339-0000-0000-0000

HD74HC4066TELL - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

高速CMOS標準ロジックIC|パッケージ：TSSOP|梱包：テーピング（リール）

HD74HC4066TELL の詳細情報

型番	HD74HC4066TELL
メーカー	RENESAS
種別	高速CMOS標準ロジックIC
データシート
Analog IC - Other Type	SPST
JESD-30 Code	R-PDSO-G14
JESD-609 Code	e0
Length	5 mm
Moisture Sensitivity Level	1
Normal Position	NO V
Number of Channels	1
Number of Functions	4
Number of Terminals	14
Off-state Isolation-Nom	50 dB
On-state Resistance Match-Nom	3 ohm
On-state Resistance-Max (Ron)	200 ohm
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
Package Body Material	PLASTIC/EPOXY
Package Code	TSSOP
Package Equivalence Code	TSSOP14,.25
Package Shape	RECTANGULAR
Package Style	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH Meter
Peak Reflow Temperature (Cel)	240
Power Supplies	2/6 V
Qualification Status	Not Qualified
Seated Height-Max	1.1 mm
Sub Category	Multiplexer or Switches
Supply Voltage-Max (Vsup)	6 V
Supply Voltage-Min (Vsup)	2 V
Supply Voltage-Nom (Vsup)	4.5 V
Surface Mount	YES
Switch-off Time-Max	23 ns
Switch-on Time-Max	23 ns
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	Tin/Lead (Sn/Pb)
Terminal Form	GULL WING
Terminal Pitch	0.65 mm
Terminal Position	DUAL
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	4.4 mm
