HD64F7058BF80L データシート

Name: HD64F7058BF80L
Brand: RENESAS
SKU: 180067503-0000-0000-0000

HD64F7058BF80L - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

HD64F7058BF80L の詳細情報

型番	HD64F7058BF80L
メーカー	RENESAS
データシート
ADC Channels	YES
Address Bus Width	22
Bit Size	32
CPU Family	SH7000
Clock Frequency-Max	20 MHz
DAC Channels	NO
DMA Channels	YES
External Data Bus Width	16
JESD-30 Code	R-PQFP-G256
JESD-609 Code	e0
Length	40 mm
Number of I/O Lines	149
Number of Terminals	256
Operating Temperature-Max	85 Cel
Operating Temperature-Min	-40 Cel
PWM Channels	YES
Package Body Material	PLASTIC/EPOXY
Package Code	FQFP
Package Equivalence Code	QFP256,1.2X1.7,20
Package Shape	RECTANGULAR
Package Style	FLATPACK Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Power Supplies	3.3,5 V
Qualification Status	Not Qualified
RAM (bytes)	49152
ROM (words)	1048576
ROM Programmability	FLASH
Seated Height-Max	3.56 mm
Speed	80 rpm
Sub Category	Microcontrollers
Supply Current-Max	150 mA
Supply Voltage-Max	3.6 V
Supply Voltage-Min	3 V
Supply Voltage-Nom	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	INDUSTRIAL
Terminal Finish	TIN LEAD
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	28 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
