HD64F2318VTE25 データシート

Name: HD64F2318VTE25
Brand: RENESAS
SKU: 180002375-0000-0000-0000

HD64F2318VTE25 - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

HD64F2318VTE25 の詳細情報

型番	HD64F2318VTE25
メーカー	RENESAS
データシート
A/D Converters	8-Ch 10-Bit
ADC Channels	YES
Additional Feature	IT ALSO HAS WIDE RANGE TEMP OF MINUS 40 TO PLUS 85
Address Bus Width	24
Bit Size	16
CPU Family	H8S/2000
Clock Frequency-Max	25 MHz
Connectivity	SCI(2)
D/A Converters	2-Ch 8-Bit
DAC Channels	YES
DMA Channels	NO
Data EEPROM Size	0
External Data Bus Width	16
JESD-30 Code	S-PQFP-G100
Length	14 mm
Moisture Sensitivity Level	3
Number of I/O Lines	79
Number of Terminals	100
On Chip Program ROM Width	8
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-40 Cel
PWM Channels	YES
Package Body Material	PLASTIC/EPOXY
Package Code	QFP
Package Equivalence Code	TQFP100,.63SQ
Package Shape	SQUARE
Package Style	FLATPACK Meter
Peak Reflow Temperature (Cel)	NOT SPECIFIED
Peripherals	POR, TIMER(8), WDT
Power Supplies	3.3 V
Qualification Status	Not Qualified
RAM (bytes)	8192
ROM (words)	262144
ROM Programmability	FLASH
Seated Height-Max	1.2 mm
Speed	25 rpm
Sub Category	Microcontrollers
Supply Voltage-Max	3.6 V
Supply Voltage-Min	3 V
Supply Voltage-Nom	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	NOT SPECIFIED
Width	14 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
