HD64F2218UTF24V データシート

Name: HD64F2218UTF24V
Brand: RENESAS
SKU: 180065983-0000-0000-0000

HD64F2218UTF24V - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

HD64F2218UTF24V の詳細情報

型番	HD64F2218UTF24V
メーカー	RENESAS
データシート
ADC Channels	YES
Additional Feature	ALSO OPERATES AT 2.4 V MINIMUM SUPPLY
Address Bus Width	24
Bit Size	16
CPU Family	H8S/2000
Clock Frequency-Max	24 MHz
DAC Channels	NO
DMA Channels	YES
External Data Bus Width	16
JESD-30 Code	S-PQFP-G100
Length	12 mm
Moisture Sensitivity Level	3
Number of I/O Lines	69
Number of Terminals	100
Operating Temperature-Max	75 Cel
Operating Temperature-Min	-20 Cel
PWM Channels	YES
Package Body Material	PLASTIC/EPOXY
Package Code	TFQFP
Package Equivalence Code	TQFP100,.55SQ,16
Package Shape	SQUARE
Package Style	FLATPACK, THIN PROFILE, FINE PITCH Meter
Peak Reflow Temperature (Cel)	260
Power Supplies	2.5/3.3 V
Qualification Status	Not Qualified
RAM (bytes)	12288
ROM (words)	131072
ROM Programmability	FLASH
Seated Height-Max	1.2 mm
Speed	24 rpm
Sub Category	Microcontrollers
Supply Voltage-Max	3.6 V
Supply Voltage-Min	3 V
Supply Voltage-Nom	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL EXTENDED
Terminal Form	GULL WING
Terminal Pitch	0.4 mm
Terminal Position	QUAD
Time@Peak Reflow Temperature-Max (s)	20
Width	12 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER
