HD6417708RF100A データシート

Name: HD6417708RF100A
Brand: RENESAS
SKU: 180004333-0000-0000-0000

HD6417708RF100A - RENESAS の商品詳細ページです。

２営業日以内に回答いたします

HD6417708RF100A の詳細情報

型番	HD6417708RF100A
メーカー	RENESAS
データシート
ADC Channels	NO
Address Bus Width	26
Bit Size	32
CPU Family	SH7000
Clock Frequency-Max	60 MHz
DAC Channels	NO
DMA Channels	NO
External Data Bus Width	32
JESD-30 Code	S-PQFP-G144
Length	20 mm
Moisture Sensitivity Level	3
Number of I/O Lines	8
Number of Terminals	144
Operating Temperature-Max	70 Cel
Operating Temperature-Min	-20 Cel
PWM Channels	NO
Package Body Material	PLASTIC/EPOXY
Package Code	LFQFP
Package Equivalence Code	QFP144,.87SQ,20
Package Shape	SQUARE
Package Style	FLATPACK, LOW PROFILE, FINE PITCH Meter
Power Supplies	3.3 V
Qualification Status	Not Qualified
RAM (bytes)	4096
ROM Programmability	FLASH
Seated Height-Max	1.7 mm
Speed	100 rpm
Sub Category	Microcontrollers
Supply Current-Max	200 mA
Supply Voltage-Max	3.6 V
Supply Voltage-Min	3 V
Supply Voltage-Nom	3.3 V
Surface Mount	YES
Technology	CMOS
Temperature Grade	COMMERCIAL
Terminal Form	GULL WING
Terminal Pitch	0.5 mm
Terminal Position	QUAD
Width	20 mm
uPs/uCs/Peripheral ICs Type	MICROCONTROLLER, RISC
